42″–80″ Extra Long Reach Full Motion TV Mount (SCL05XL)

SureMount 42″–80″ Extra Long Reach Full Motion TV Mount (SCL05XL)

The SureMount SCL05XL is a heavy-duty, extra-long-reach full motion TV wall mount designed for installations where a standard cantilever bracket simply doesn’t provide enough extension.

With an impressive 1010mm maximum reach, the SCL05XL can bring your television more than a metre out from the wall, providing exceptional flexibility for corner installations, large rooms and open-plan living areas.

Its single-arm design provides excellent freedom of movement, allowing the television to be pulled away from the wall and swivelled towards different viewing areas. This makes the SCL05XL particularly useful where you want to watch the same television from the lounge, dining area or kitchen.

When not required, the mount folds back to approximately 83mm from the wall for a clean, unobtrusive installation.

Built from heavy-gauge steel and supporting televisions weighing up to 50kg, the SCL05XL combines exceptional reach with the strength required for larger screens.

---

🟨 Key Features

📺 Fits Most 42″–80″ TVs
Designed for larger televisions weighing up to 50kg.

↔️ Extra-Long 1010mm Reach
Extends more than one metre from the wall, making it ideal for corner mounting and open-plan spaces.

📏 Retracts to Approximately 83mm
Folds neatly back towards the wall when the extra reach isn’t required.

📐 VESA 200×200 to 600×400mm
Supports a wide range of mounting patterns commonly found on medium and large televisions.

🏋️ 50kg Maximum Load
Heavy-duty construction provides reliable support for compatible larger TVs.

🦾 Single-Arm Full Motion Design
Provides excellent freedom of movement and greater positioning flexibility than many dual-arm mounts.

🔄 Wide Swivel Range
Allows the television to be angled towards different seating or viewing areas. Actual swivel depends on TV width and clearance.

↕️ +5° to -12° Tilt Adjustment
Fine-tune the screen angle for a more comfortable viewing position and reduced reflections.

📐 Ideal for Corner Installations
The combination of long reach and single-arm articulation makes the SCL05XL particularly effective when mounting near a corner.

🏠 Excellent for Open-Plan Living
Angle the TV towards the lounge, dining area or kitchen depending on where you’re watching from.

🔌 Integrated Cable Management
Helps keep TV cables organised as the mount extends and swivels.

🛠️ Heavy-Gauge Steel Construction
Designed to provide strong, durable support throughout the mount’s full range of movement.

📦 Complete Mounting Kit Included
Supplied with mounting hardware for wall and TV installation.

---

📐 Measurements – SCL05XL

• Maximum reach: 1010mm
• Minimum wall depth: 83mm
• Wall backplate: 673.5 × 259mm
• Front TV mounting assembly: 886 × 430mm
• Maximum supported VESA: 600 × 400mm

The 886 × 430mm measurement is the physical overall size of the front TV mounting assembly. It is different from the maximum supported VESA mounting-hole pattern of 600 × 400mm.

📐 Measurements:
SCL05XL Extra Long Reach Full Motion TV Mount Measurements

---

📄 Technical Documents

📘 Product Manual:
SCL05XL Product Manual

📐 Measurements:
SCL05XL Measurements

---

🔍 SCL05XL vs SCL10XL – Which One Should You Choose?

Both the SCL05XL and SCL10XL are extra-long-reach full motion TV mounts designed for larger televisions, but their different arm designs make them better suited to different installations.

🟨 SCL05XL – Maximum Reach & Positioning Flexibility

↔️ Maximum reach: 1010mm

🦾 Single-arm design

📐 Excellent swivel and positioning flexibility

🏠 Particularly well suited to corner installations

🔄 Ideal where the TV needs to be pulled well away from the wall and turned towards different viewing areas

The single-arm design provides greater freedom when positioning the television, particularly where a wide range of movement is required.

🟨 SCL10XL – Strength & Stability

↔️ Maximum reach: 910mm

🦾 Dual-arm design

🏋️ More rigid support for larger televisions

🔄 Particularly well suited to TVs that will be moved regularly

📐 Reduced tendency for levelling variation as the screen is repositioned

The dual-arm design sacrifices some reach and swivel flexibility in exchange for a more rigid and stable platform.

⚖️ Quick Comparison

➡️ Choose the SCL05XL when maximum reach, corner mounting and positioning flexibility are the priorities.

➡️ Choose the SCL10XL when stability and frequent repositioning of a larger television are more important.

---

💡 Installer Insight

Extra-long-reach mounts place significantly more leverage on the wall than conventional TV brackets when fully extended.

With the SCL05XL capable of positioning a 50kg television more than one metre from the wall, correct structural fixing is particularly important.

The mount must be securely attached to suitable structural framing or a structurally sound concrete or masonry wall using appropriate fixings.

---

📐 Why Use the SCL05XL for Corner Mounting?

Mounting a television in a corner can be difficult with a conventional full motion bracket because there may not be enough extension to bring the television clear of the adjacent wall.

The SCL05XL’s combination of 1010mm reach and single-arm articulation allows the television to be pulled well away from its mounting wall before being swivelled towards the required viewing position.

📐 Maximise Available Space

Corners are often underutilised. Positioning the TV in a corner can free up valuable flat wall space and provide more options for arranging furniture.

👀 Better Viewing Angles

The long-reach full motion design allows the television to be angled towards different seating positions or areas of the room.

🏠 Ideal for Open-Plan Living

The SCL05XL works particularly well where the television needs to be viewed from a lounge, dining area or kitchen.

🚪 Works Around Windows & Doors

Where conventional TV placement is restricted by windows, doors, furniture or other architectural features, the extra reach can provide considerably more installation flexibility.

🔧 Offset Pivot Design

The SCL05XL’s offset single-arm pivot design allows the television to move substantially away from its original wall position before being swivelled.

This makes it particularly effective when the mounting position is close to a corner or adjacent wall.

---

❓ FAQs – 42″–80″ Extra Long Reach Full Motion TV Mount (SCL05XL)

1️⃣ What size TVs does the SCL05XL support?

The SCL05XL is designed for most 42″–80″ TVs, provided the television weighs no more than 50kg and has a compatible VESA mounting pattern.

Always check the TV’s weight and VESA dimensions rather than relying solely on screen size.

2️⃣ How far does the SCL05XL extend from the wall?

The SCL05XL provides an impressive 1010mm maximum reach, allowing the television to extend more than one metre from the wall.

When folded back, the mount sits approximately 83mm from the wall.

3️⃣ What VESA mounting patterns does it support?

The SCL05XL supports VESA mounting patterns from 200×200mm through to 600×400mm.

The physical front TV mounting assembly measures approximately 886 × 430mm, but this should not be confused with its maximum supported VESA pattern.

4️⃣ Is the SCL05XL suitable for corner mounting?

Yes.

Corner mounting is one of the applications where the SCL05XL really stands out.

Its 1010mm extension and single-arm articulation allow the television to be pulled well away from the wall before being swivelled towards the required viewing position.

5️⃣ Can I use it to watch TV from different parts of a room?

Yes.

The combination of long extension and wide swivel makes the SCL05XL particularly useful in open-plan living areas, where you may want to angle the television towards the lounge at one time and the kitchen or dining area at another.

6️⃣ How much can the TV tilt?

The television can be adjusted approximately +5° upward and -12° downward, allowing the viewing angle to be fine-tuned after installation.

7️⃣ How far can the TV swivel?

The SCL05XL provides a wide swivel range.

The actual available swivel angle will depend on the width of your television, how far the mount is extended and surrounding wall clearance.

Smaller televisions will generally achieve a greater swivel angle than larger screens.

8️⃣ What is the maximum TV weight?

The SCL05XL supports televisions weighing up to 50kg.

The weight limit must not be exceeded regardless of the television’s screen size.

9️⃣ Is the SCL05XL suitable for regular movement?

Yes.

The SCL05XL can be repositioned as required. However, if you have a particularly large television that will be moved in and out frequently, you may prefer the dual-arm SCL10XL, which provides additional rigidity and stability.

🔟 What is the main difference between the SCL05XL and SCL10XL?

The SCL05XL prioritises maximum reach and flexibility. Its single-arm design extends up to 1010mm and provides excellent freedom of movement.

The SCL10XL prioritises stability. Its dual-arm design extends up to 910mm and provides a more rigid platform for larger televisions that are regularly repositioned.

1️⃣1️⃣ Can the SCL05XL be mounted directly to plasterboard?

No.

The SCL05XL must be securely attached to suitable structural framing or a structurally sound concrete or masonry wall.

It should not be mounted directly to plasterboard/drywall alone.

1️⃣2️⃣ Why is structural fixing particularly important with this mount?

At full extension, the television can sit more than one metre from the wall.

This creates considerably greater leverage on the wall and mounting fixings than a conventional low-profile TV bracket, particularly with a heavier television.
