65″–95″ Super Slim Fixed TV Wall Mount (SFSS05)

SureMount 65″–95″ Super Slim Fixed TV Wall Mount (SFSS05)

The SureMount® SFSS05 Super Slim Fixed TV Wall Mount is a heavy-duty, ultra-low-profile mounting solution designed specifically for large TVs from 65″–95″ and weighing up to 100 kg.

Despite its heavy-duty capacity, the SFSS05 positions the TV just 24 mm from the wall, creating a clean, modern, near-flush appearance.

For large-screen installations, the SFSS05 features an extra-wide wall mounting plate with fixing holes spanning up to 1155 mm. This provides installers with considerably more flexibility when positioning wall fixings and makes it easier to secure the mount across multiple wall studs where the wall construction allows.

The TV mounting arms can also slide horizontally along the wall plate, allowing the screen to be centred precisely after the bracket has been securely fixed to the wall.

For additional security, the SFSS05 incorporates the same security locking bar system as the SFSS03. Once the TV is installed, the bar slides through the mounting assembly to positively lock the TV arms onto the wall bracket. A padlock can be fitted at the end of the locking bar to help prevent unauthorised removal.

The SFSS05 supports VESA mounting patterns up to 700 × 500 mm as standard, while the included vertical extension arms increase compatibility up to 700 × 800 mm for TVs and displays with taller mounting patterns.

Ideal for large living spaces, offices, boardrooms, hotels, schools, retail displays, hospitality venues and commercial installations where strength, security and an exceptionally slim profile are required.

---

🟨 Key Features

📺 Fits Most 65″–95″ TVs
Designed specifically for large-screen TVs with compatible VESA mounting patterns.

🏋️ Heavy-Duty 100 kg Capacity
Strong steel construction provides secure support for TVs weighing up to 100 kg.

📏 Super Slim 24 mm Profile
Positions even very large TVs just 24 mm from the wall for a clean, near-flush installation.

🧱 Extra-Wide Wall Mounting Plate
Fixing holes span up to 1155 mm, providing excellent flexibility when positioning the bracket across wall studs.

🔩 Multi-Stud Fixing Flexibility
The wide wall plate provides installers with more options for picking up multiple structural fixing points, particularly important with large and heavy TVs.

↔️ Sliding TV Mounting Arms
The TV mounting arms can slide horizontally along the wall plate, allowing the TV to be centred left or right after installation.

📐 VESA Compatibility up to 700 × 500 mm
Generous standard mounting range accommodates a wide variety of large TVs.

↕️ Extension Arms Included – Up to 700 × 800 mm VESA
Vertical extension arms are supplied with the SFSS05, increasing compatibility for TVs with taller VESA mounting patterns.

🔒 Security Locking Bar
The horizontal locking bar secures the TV mounting arms firmly to the wall bracket, preventing the TV from simply being lifted off the mount.

🔐 Padlock Compatible
A padlock can be fitted to the security locking bar to help deter theft or unauthorised removal.

🛠️ Heavy-Duty Steel Construction
Designed for the additional size and weight of large-format TVs.

📦 Mounting Hardware Included
Supplied with mounting hardware for typical TV and wall installations.

---

⚠️ Compatibility & Installation

Before installation, check that your TV falls within the following requirements:

• Recommended TV size: 65″–95″
• Maximum TV weight: 100 kg
• Standard VESA: Up to 700 × 500 mm
• Extended VESA: Up to 700 × 800 mm
• Vertical VESA extension arms: Included
• Wall clearance: 24 mm
• Maximum wall fixing-hole span: 1155 mm
• Mount type: Fixed
• Horizontal adjustment: Sliding TV mounting arms
• Security: Locking bar secures TV arms to wall bracket
• Anti-theft provision: Security bar accepts a padlock

With a TV of this size and weight, the wall structure and fixing method are critical. The bracket should always be secured to suitable structural fixing points appropriate for the wall construction and anticipated load.

Because the SFSS05 positions the TV only 24 mm from the wall, cable and power outlet locations should also be considered before installation.

---

🧱 Designed for Multi-Stud Installation

One of the major advantages of the SFSS05 is its extra-wide wall plate.

With fixing holes spanning up to 1155 mm, installers have considerably more flexibility to position fixings across multiple wall studs rather than being restricted to a narrow mounting area.

Depending on the stud layout and wall construction, the wide plate can provide the opportunity to secure the mount across three studs.

This is particularly useful when installing large and heavy TVs, where distributing the mounting load across multiple structural fixing points can provide a more secure installation.

The wall plate does not necessarily need to be mounted perfectly symmetrically behind the TV. Once securely installed, the sliding TV mounting arms allow the screen to be repositioned horizontally to achieve the required final position.

---

🔧 Installer’s Tip – Use the Width of the Wall Plate

When installing a large TV, don’t focus only on centring the wall plate behind the screen.

The SFSS05 gives you up to 1155 mm of fixing-hole span, so use that width to locate the most suitable structural fixing points available.

Where the wall construction permits, fixing positions can be selected across the plate to pick up additional studs, even if those fixing points are not perfectly symmetrical.

Once the wall plate is securely installed, the TV can then be slid horizontally along the bracket to achieve the desired final position.

This gives the installer the flexibility to prioritise secure structural fixing first and precise TV positioning second.

---

🔒 Securely Locks the TV to the Bracket

Once the TV has been hung and positioned, the SFSS05’s horizontal security locking bar slides through the bottom of the mounting assembly, positively locking the TV mounting arms to the wall bracket.

The bar incorporates a retaining tab at one end, meaning it can only be withdrawn in one direction.

At the opposite end is a padlock hole, allowing a padlock to be fitted to prevent the locking bar from being removed.

This provides two benefits:

✔ Secure attachment
The TV cannot simply be lifted upwards and removed from the wall bracket once the locking bar is engaged.

✔ Theft deterrence
Adding a padlock helps prevent unauthorised removal of the TV.

This makes the SFSS05 particularly useful for hotels, schools, offices, retail environments, hospitality venues and other public or commercial installations.

---

🔌 Installer’s Tip – Allow for Cable Clearance

The 24 mm super-slim profile gives the SFSS05 its clean appearance, but there is limited space behind the TV for cables and connectors.

Before installation, check the location and direction of the TV’s:

• HDMI connections
• Power connection
• Aerial connection
• Network connection
• Other AV inputs

Where appropriate, right-angle connectors or recessed wall outlets can make installation considerably easier.

Suitable spacers may also be used between the TV and the upper mounting points of the bracket where appropriate for the TV and installation. This can provide a small amount of additional cable clearance while introducing a very slight forward angle.

---

↕️ 700 × 800 VESA Extension Arms Included

Unlike the SFSS03, where the additional vertical VESA extension is optional, the SFSS05 includes the vertical extension arms.

Standard configuration: up to 700 × 500 mm VESA

With supplied extension arms: up to 700 × 800 mm VESA

This gives the SFSS05 considerably more flexibility when installing large TVs with tall mounting patterns.

---

📄 Technical Documents

SFSS05 Measurements – View SFSS05 Measurements

SFSS01 / SFSS03 / SFSS05 Installation Manual – View Installation Manual

SFSS05 Datasheet – SureMount_SFSS05_Datasheet

---

❓ FAQs – SFSS05 Super Slim Fixed TV Wall Mount

1️⃣ What size TVs does the SFSS05 fit?

The SFSS05 is designed for most 65″–95″ TVs, provided the TV weighs no more than 100 kg and has a compatible VESA mounting pattern.

---

2️⃣ How close does a large TV sit to the wall?

Just 24 mm.

Despite being designed for TVs weighing up to 100 kg, the SFSS05 maintains the same ultra-slim wall clearance as the smaller SFSS03.

---

3️⃣ What VESA mounting patterns does the SFSS05 support?

The standard bracket supports VESA patterns up to 700 × 500 mm.

The included vertical extension arms increase the maximum vertical mounting pattern to 700 × 800 mm.

---

4️⃣ Why is the SFSS05 wall plate so wide?

The extra-wide wall plate provides fixing holes spanning up to 1155 mm, giving installers greater flexibility when locating suitable structural fixing points.

This is particularly useful with large TVs because it provides more opportunities to secure the bracket across multiple wall studs.

---

5️⃣ Can the SFSS05 be fixed across three studs?

Yes, where the wall construction and stud positions allow.

The wide wall plate gives installers considerably more freedom to select fixing positions and can allow the bracket to be secured across three studs rather than two.

The appropriate fixing method will depend on the wall structure and installation.

---

6️⃣ What if the wall studs aren’t centred behind my TV?

This is where the SFSS05’s sliding mounting arms are particularly useful.

The wall plate can be positioned to take advantage of the best available structural fixing points. Once installed, the TV mounting arms can slide horizontally along the plate, allowing the TV to be centred independently of the wall plate position.

---

7️⃣ What does the security locking bar do?

Once the TV is installed, the horizontal locking bar slides through the mounting assembly, preventing the TV arms from being lifted off the wall bracket.

A retaining tab at one end prevents the bar from passing completely through the bracket.

---

8️⃣ Can I padlock the TV to the bracket?

Yes.

The opposite end of the security locking bar has a padlock hole. Adding a padlock prevents the locking bar from being withdrawn and helps deter theft or unauthorised removal of the TV.

---

9️⃣ Can I tilt or swivel the TV?

No. The SFSS05 is a fixed TV wall mount.

Its purpose is to provide a strong, secure and extremely low-profile installation for large TVs.

---

🔟 Is there enough room behind the TV for cables?

The SFSS05 provides only 24 mm of wall clearance, so cable planning is important.

TVs with side- or downward-facing connections are generally easier to accommodate. Rear-facing connections may benefit from right-angle connectors, recessed wall outlets or suitable spacing.

---

1️⃣1️⃣ Is the SFSS05 suitable for commercial installations?

Yes. Its combination of 100 kg load capacity, extra-wide wall plate, multi-stud fixing flexibility, 24 mm profile and padlock-compatible security bar makes it particularly well suited to large-screen commercial installations.

Typical applications include hotels, schools, offices, boardrooms, retail stores, hospitality venues, waiting areas and other public spaces.
